The latest flagship mobile by Samsung Galaxy is none other than the Samsung Galaxy S24 Ultra in 2024. But if your Galaxy S24 Ultra screen gets damaged accidentally don’t panic. We have brought the Samsung Galaxy S24 Ultra Screen Replacement Step By Step guide to help you get back that amazing screen and display of Samsung Galaxy S24 Ultra. In this guide we will show you pictorial illustrations and write down every step with all the precautions. We know your Galaxy S24 Ultra is not just a phone for you it’s your dream device! So without wasting time move toward replacing the Samsung Galaxy S24 Ultra Screen.
Gathering Tools For Samsung Galaxy S24 Ultra Screen Replacement
Before you start replacing the Samsung Galaxy S24 Ultra screen you need to gather all the necessary tools. The right tools will make the job easier and help you avoid mistakes. So here are the tools.
*You will need a Replacement Screen. But please make sure you have the correct screen for the Galaxy S24 Ultra.
*Gather Small Phillips Screwdriver to remove tiny screws.
*Plastic Pry Tools to open the phone without scratching it.
*Suction Cup to lift the screen gently.
*Tweezers for handling small parts and screws.
*Isopropyl Alcohol to clean the phone before and after the repair.
*Microfiber Cloth to wipe the screen and keep it clean.
*Heat Gun or Hairdryer to soften adhesive and make it easier to remove the screen.
*Adhesive Strips or Glue to secure the new screen in place.
Prepare Area for Replacing the Samsung Galaxy S24 Ultra Screen
Having the correct workspace is very important when replacing the screen on your Samsung Galaxy S24 Ultra. A good area will help you work better and reduce the chances of mistakes. Here are things you can keep in your mind before starting the screen replacement.
*Go for a Clean Surface. A clean table or desk will help you proceed with your work without disturbance and also avoid dust.
*Good Lighting is necessary. The reason is enough bright areas will allow you to see clearly everything especially tiny screws and parts.
*Area with Zero Distractions. A quiet place will help you focus on your work without interruptions.
*Comfortable Seating. Use a chair that supports your back and helps you sit comfortably.
*Proper Ventilation will make sure the room has good airflow especially if you use adhesive.
*Keep Tools within your easy reach.
Step #1. Remove The Back Cover
*So our first step is removing the back cover of the Samsung Galaxy S24 Ultra.
*Without removing the back cover, we cannot replace the screen and display.
*There are some important disconnections before removing and replacing the screen.
*Here you can use a heat gun or a hair dryer to melt the adhesive and secure the back cover.
*Otherwise Isopropyl Alcohol is also helpful for dissolving and removing sticky adhesive.
*You need to be careful while applying heat. Excessive heat can cause severe damage.
Step #2. Apply Suction Cup
*Well if you started with a heat gun or a hair dryer then apply a suction tool to the bottom back of the S24 Ultra.
Otherwise you can insert an opening pick and drip some drops of Isopropyl Alcohol. Keep moving the opening pick and again apply Isopropyl Alcohol and move the pick until the entire cover gets detached.
Step #3. Insert Opening Pick
*After the suction tool has created a line gap it’s time to insert an opening pick.
*Move the opening pick all around the edges to cut the adhesive.
*The adhesive will cut easily because of heat application.
Step #4. Separate the Back Cover
After cutting the adhesive from all sides you can easily separate the back cover and keep it aside carefully. Remember that in the Samsung Galaxy S24 Ultra the back cover is made up of two materials: solid polycarbonate on the back and flexible TPU on the sides. It also has a strong magnet for MagSafe accessories.
Step #5. Unfasten Screws
*The wireless charging coil and NFC antenna must be disconnected from the main board.
*Now you need to remove the 10 Phillips screws.
*You can see the marks on the screws that should be removed in the given pictorial guide.
*Keep all the screws safe in a secure place.
*Opening these ten screws will allow you to disconnect the charging coil and NFC antenna from the main board.
*After removing all the screws take a flat point spudger and detach the connection cable as shown in the picture.
*Lift and peel the NFC antenna and charging foil to separate it.
Step #6. Battery Disconnection
*Well at this point the battery cable needs to be disconnected.
*You can use use flat end spudger or an opening pick to pry up and disconnect the battery from the board.
Step #7. Remove Speaker Assembly
*This is the time to remove the speaker assembly.
*All the screws we have already removed
*Now pry up the speaker assembly with the help of any flat point tool.
*Lift it with your fingers.
*Careful keep it aside.
Step #8. Disconnection Of Screen Flex Cable
*At this point you need to remove the flex cable for the screen.
*Pry it up from the bottom side of the S24 Ultra.
Step #9. Disconnect Spen Function Flex Cable
*Another important flex cable to disconnect is the Spen function flex cable.
*Pry it with the hemp of a thin point spudger and disconnect it from the main board.
Step #10. Flip The Samsung Galaxy S24 Ultra To the Front
*Now you need to work on the screen to remove it.
*Please remember to apply tape to the entire screen if it is damaged. Otherwise you can go without taping.
Step #11. Heat The Screen For Melting The Adhesive
*Here you can use a hair dryer or heat gun for melting the adhesive.
*It will separate the screen from the frame without damaging the parts or clips.
*Please don’t apply excessive heat. Overheating can damage other parts so the phone must be exposed to heat for 45 to 60 seconds. You can use more heat if needed.
*Keep checking the screen’s warmness with your hand.
Step #12. Apply Suction Tool
*When it comes to the Samsung Galaxy S24 Ultra the screen replacement is a little fragile because there is not enough room to apply the glue. That is why the bezel around the screen is very thin so adhesive is used to keep the screen on its frame correctly. So it’s really impossible to pry up the screen without damaging it. It means you need to separate extremely sticky glue between the frame and the screen.
*Now you can apply a suction tool for lifting the screen a create a line gap.
*If the screen accidentally comes out separately without its display you don’t need to worry. Because we are working on replacing it. And this means the screen is already unusable.
Step #13. Insert Opening Pick
*It’s time to insert an opening pick into the gap and move it to cut the adhesive.
*In the pictorial illustration you will see the screen is already damaged as it is coming out without a display sheet. But don’t panic your point is to replace the screen.
*Move the opening pick all around the screen’s edges.
*Now the screen glass has separated.
*Insert the opening pick under the display sheet to remove it.
*You can peel it by pulling with the help of your hands.
Step #14. Remove the Leftover adhesive Of the Screen from the Frame
*Once the screen and the display are fully removed you also need to remove the leftover adhesive of the screen from the frame.
*Well you can clean it and pry it off with the use of your hand otherwise use some Isopropyl Alcohol to clean up the adhesive residual or you can use an adhesive removal tool. The adhesive removal tool rotates fast and peels off all the adhesive residual so quickly.
Step #15. Apply New Original Pre-Cut Adhesive
*Once you have removed all the residual adhesive and it is completely clean as shown in the picture you can apply the pre-cut adhesive.
*Peel the blue sticker and apply it carefully to the phone’s frame. This will help ensure a proper seal. However if you want to apply your own adhesive rather than pre-cut adhesive you can go for B7000 adhesive for a good bond. But it will not be the same as the original and will not give you that protection.
*Press the pre-cut adhesive with the help of your fingers. Remember at this point the blue sheet is not removed.
*Now it’s time to remove the blue sheet from the adhesive.
*Now apply the next light green shade adhesive sheet part to the middle of the phone.
*Press this part also with your finger so that the adhesive strips stick to it correctly.
*Now peel off the extra sheet and leave only the adhesive on the phone.
*It is time to apply the third part of the adhesive around the bottom edges of the phone.
*Again press it with the help of your finger and let the adhesive attach to the phone. And then peel off the plastic sheet.
Once all the adhesives have been installed. You can install the new screen of the Samsung Galaxy S24 Ultra.
Step #16. Apply The Screen On the Samsung Galaxy S24 Ultra
*Now you can apply the screen on your S24 Ultra. But before applying you need to make sure the screen flex on the top side of the screen should be connected through the opening of the mid-frame.
*Place the screen exactly on the mod-frame connection point and set the screen correctly on the phone.
*Gentle pressing with the help of your finger will also allow the screen to settle down correctly on the frame and stick with adhesive.
*Now that the screen has been applied to the Samsung Galaxy S24 Ultra.
Step #17. Reassemble All The Connections And Flex Cables
*After installing the new screen to need to flip the phone and reassemble all the cables.
*Connect the Spen Flex cable.
*Snug fit the main flex cable.
*Install the speaker assembly and make sure it is correctly placed in its place so that you can easily fasten its screws.
Step #18. Connect the Battery Cable
*After connecting all the cables and installing screws you will reconnect the battery at this stage.
*The battery should be reconnected after reassembling all the other parts and connections. This will help you to avoid battery mishaps.
Step #19. Reinstall the Wireless Charging Coil
*It’s time to reinstall the wireless charging coil.
*Carefully install it again
*Check every screw hole is correctly in their place.
*Press gently with your finger and make sure the charging coil is correctly patched.
*Make sure to connect the connection with the main board.
*Now you can fasten all the screws back in place.
Step #20. Replacing Adhesive On The Backplate and Battery Cover
*We will now learn how to replace the adhesive on the Samsung Galaxy S24 Ultra’s Backplate (back cover).
*After removing your back back cover for once you need to replace the adhesive.
*The first step is to remove the old adhesive from the back plate and the battery cover.
*Then you have two options for the new adhesive. Either you can use a pre-cut adhesive for the Samsung Galaxy S24 Ultra Back palate or an adhesive rework kit to frame for reinstalling the back cover.
*Well in this guide we are using a pre-cut adhesive sheet for the S24 Ultra back plate.
*It is very simple to apply. Just place it correctly according to its shape on the frame.
*Press with your finger so that it can stick to the frame.
*Now remove the plastic sheet
Step #21. Reapply The Backplate And The Battery Cover
*When you have applied the adhesive on the Samsung Galaxy S24 Ultra’s backplate and battery cover apply it to the phone.
*Make sure it’s correct place because it will stick with the adhesive.
*The correct way to measure the right direction is to check with the camera holes and try to place the cover correctly according to the camera holes.
*Now secure the back cover on the frame and gently press its edges so that it can stick with adhesive.
Congratulations!
You are done with the Samsung Galaxy S24 Ultra Screen Replacement. Also now you know very well how to apply the adhesive on the screen and the backplate. It’s time to turn on your S24 Ultra to check how your new screen works. It is highly recommended that you choose the original Samsung Galaxy S24 Ultra Screen Replacement. Otherwise you may have to suffer complications or unwanted results.
However it’s up for this guide. Wish you the very best of luck with your amazing Samsung Galaxy S24 Ultra. If you have anything to talk about your phone please feel free to write us in the comment section or you can contact us through Email and content number. Please share your thoughts! See you in the next guide!
